SE0607
Proportional Controls、Automatic Pothole Protection、Drivable at Full Height、Non-Marking Tyres、Automatic Braking System、Emergency Lowering System、Emergency Stop Button、Cylinder Holding Valve、Onboard Diagnostic System
|
MODEL
|
SE0607
|
|---|---|
|
Working height, max
|
6.00m
|
|
Platform height, max
|
4.00m
|
|
Loading capacity
|
240kg
|
|
Occupants
|
1
|
|
Overall length
|
1.32m
|
|
Overall width
|
0.76m
|
|
Overall height
|
1.83m
|
|
Platform dimension
|
1.15×0.60m
|
|
Platform extension length
|
0.55m
|
|
Extension load
|
100kg
|
|
Wheelbase
|
1.00m
|
|
Turning radius
|
0
|
|
Travel speed (stowed)
|
4km/h
|
|
Travel speed (raised)
|
0.5km/h
|
|
Up/Down speed
|
34/25sec
|
|
Working slope, max
|
X-1.5° Y-2.0°
|
|
Gradeability
|
25%
|
|
Tyres
|
Φ230×80mm
|
|
Driving motor
|
24V/0.4kW
|
|
Lifting motor
|
24V/1.3kW
|
|
Battery
|
2×12V/100Ah
|
|
Charger
|
24V/15A
|
|
Weight
|
680kg
|
