Hi11T
AC Driving Motor、Proportional Joystick Controls、Self-Locking Gate、Drivable at Full Height、Non-Marking Tyres、4×2 Drive、Automatic Braking System、Emergency Descent System、Tubing Explosion-Proof System、Fault Diagnosis System、Tilt Sensor Alarm、Motion Alarm、345° Turret Rotation、Horn、Hour Meter、Charging Protection System、Flashing Beacon、Charging Indicator、Manual Brake Release、Lanyard Attachment Points、Tie-Down and Lifting Points、Platform Load Sense System、Emergency Stop Button、Swing Out Components Cover
|
MODEL
|
Hi11T
|
|---|---|
|
Working height, max
|
11.20m
|
|
Platform height, max
|
9.20m
|
|
Horizontal outreach, max
|
3.00m
|
|
Up and over height
|
7.89m
|
|
Guardrail height
|
1.10m
|
|
Overall length
|
2.53m
|
|
Overall width
|
1.10m
|
|
Overall height (stowed)
|
1.99m
|
|
Platform dimension
|
0.62×0.87m
|
|
Ground clearance (stowed)
|
70mm
|
|
Ground clearance (raised)
|
19mm
|
|
Wheelbase
|
1.22m
|
|
Loading capacity
|
220kg
|
|
Occupants
|
2
|
|
Turning radius(inside/outside)
|
0.23/1.65m
|
|
Turret rotation
|
345°
|
|
Jib movement
|
130°
|
|
Travel speed (stowed)
|
4.5km/h
|
|
Travel speed (raised)
|
0.5km/h
|
|
Up/Down speed
|
42/38s
|
|
Working slope, max
|
X-2° Y-2°
|
|
Gradeability
|
25%
|
|
Tyres
|
Φ381×127mm
|
|
Driving motor
|
24V/0.9kW
|
|
Lifting motor
|
24V/3.3kW
|
|
Battery
|
24V/240Ah
|
|
Charger
|
24V/30A
|
| Weight | 2950kg |
